ISC Triple Action Snap - New updated version!
The ISC Triple Action Aluminum Snaphook is safer than traditional snaps, but very easy to use.
| Height (mm) | 140 |
|---|---|
| Height (inches) | 5 1/2 |
| Width (mm) | 71 |
| Width (inches) | 2 4/5 |
| Thickness (mm) | 18 |
| Thickness (inches) | 5/7 |
| Weight (grams) | 102 |
| Weight (ounces) | 3 3/5 |
| Gate opening gap (mm) | 22 |
| Gate opening gap (inches) | 6/7 |
| Diameter of profile at top (mm) | 14 |
| Diameter of profile at top (inches) | 5/9 |
| Eye diameter (mm) | 20 |
| Eye diameter (inches) | 4/5 |
| Number of actions | 3 |
| Body material | Aluminium |
| Other component material | Stainless steel |
| Body finish | Anodised |
| Gate/barrel finish | Anodised |
| Body colour | Grey or black |
| Gate/barrel colour | Red or black |
| (MBS) Minimum Breaking Strain - gate closed (kN) | 27 |
| (MBS) Minimum Breaking Strain - gate closed (lbf) | 6070 |
| Proof loaded (kN) | 16 |
| Proof loaded (lbf) | 3596 |
